Nominal data
Motor M2S052-CA
Phase 1~
Nominal voltage / VAC 230
Frequency / Hz 50
Type of data definition fa
Valid for approval / standard CE
Speed (rpm) / min-1 2800
Power input / W 45
Current draw / A 0.31
Max. back pressure / Pa 80
Min. ambient temperature / °C -25
Max. ambient temperature / °C 50
Starting current / A 0.45
Technical features
Mass 1.1 kg
Size 130 mm
Motor size 52
Surface of rotor Rotor open,
coated in black
Material of blades Sheet steel, coated in black
Material of wall ring Die-cast aluminium, coated in black
Number of blades 7
Direction of air flow V
Direction of rotation Counter-clockwise, seen on rotor
Type of protection IP20
Insulation class "B"
Humidity (F) / environmental protection class (H) H0+
Mounting position Any Condensation drainage holes None,
open rotor Operation mode S1 Motor bearing Ball bearing Touch current acc.
IEC 60990 (measuring network Fig. 4, TN system) < 0.75 mA
Motor protection Thermal overload protector (TOP) wired internally Protection class I (if protective earth is connected by customer at the connection point of the housing)
Product conforming to standard EN 60335-1; CE Approval VDE; CSA C22.2 no. 113; CCC; EAC; UL 507
